產品描述
| CPD20J-R電動平衡重式叉車參數表 | |||||||||||||
| 特征 distinguishing mark | |||||||||||||
| 1.1 | 制造商 | Manufacturer | 加力(JIALIFT) | 加力(JIALIFT) | 加力(JIALIFT) | ||||||||
| 1.2 | 型號 | Manufacturer's type designation | CPD20J-R | CPD20J-R | CPD20J-R | ||||||||
| 1.3 | 驅動方式 | Drive | 電動(electric) | 電動(electric) | 電動(electric) | ||||||||
| 1.4 | 駕駛方式 | Operator type | 步行(pedestrian) | 步行(pedestrian) | 步行(pedestrian) | ||||||||
| 1.5 | 額定載荷 | Load capacity | Q (kg) | 2000 | 2000 | 2000 | |||||||
| 1.6 | 載荷中心距 | Load center distance | c (mm) | 500 | 500 | 500 | |||||||
| 1.7 | 前懸距 | centre of drive axle to fork | x (mm) | 174 | 174 | 174 | |||||||
| 1.8 | 軸距 | Wheelbase | y (mm) | 1654 | 1654 | 1654 | |||||||
| 重量Weight | |||||||||||||
| 2.1 | 自重（含電瓶） | Service weight （include battery） | kg | 2580 | 2970 | 3240 | |||||||
| 2.2 | 軸負載，滿載時前/后軸 | Axle loading,laden front/rear | kg | 3981/599 | 4324/646 | 4559/681 | |||||||
| 2.3 | 軸負載，空載時前/后軸 | Axle loading,unladen front/rear | kg | 1185/1395 | 1365/1605 | 1520/1720 | |||||||
| 輪胎 ，底盤Types,Chassis | |||||||||||||
| 3.1 | 輪子類型，驅動輪/承載輪 | Tyre type driving wheels/loading wheels | 聚氨酯（polyurethane） | 聚氨酯（polyurethane） | 聚氨酯（polyurethane） | ||||||||
| 3.2 | 輪子尺寸，前輪（直徑×寬度） | Tyre size,front（diameter×width） | Φ×w(mm) | Φ250×120 | Φ250×120 | Φ250×120 | |||||||
| 3.3 | 驅動輪尺寸 | Tyre size ，rear（diameter×width） | Φ×w(mm) | Φ250×127（PU） | Φ250×127（PU） | Φ250×127（PU） | |||||||
| 3.4 | 驅動輪，平衡輪/承載輪數量（x=驅動輪） | Wheels, number driving，caster/loading (x=drive wheels) | 1，4/2 | 1，4/2 | 1，4/2 | ||||||||
| 3.5 | 輪距，承載端 | Tread,front | b11 (mm) | 976 | 976 | 976 | |||||||
| 3.6 | 輪距，驅動端 | Thread,rear | b10 (mm) | 0 | 0 | 0 | |||||||
| 尺寸 Dimensions | |||||||||||||
| 4.1 | 門架/貨叉傾斜 前傾/后傾 | Mast/fork carriage tilt, forward/backward | a/b (°) | 3/5 | 3/5 | 3/5 | |||||||
| 4.2 | 門架縮回時高度 | Height,mast lowered | h1 (mm) | 1995 | 2245 | 2495 | 2190 | 2357 | 2524 | 2690 | 1995 | 2245 | 2495 |
| 4.3 | 自由提升高度 | Free lift | h2 (mm) | 0 | 0 | 0 | 1305 | 1470 | 1639 | 1805 | 1120 | 1370 | 1620 |
| 4.4 | 提升高度 | Lift height | h3 (mm) | 3000 | 3500 | 4000 | 4500 | 5000 | 5500 | 6000 | 3000 | 3500 | 4000 |
| 4.5 | 作業時門架最大高度 | Maximum height of gantry | h4 (mm) | 3865 | 4365 | 4865 | 5420 | 5920 | 6420 | 6920 | 3865 | 4365 | 4865 |
| 4.6 | 貨叉下降后叉面高度 | Lowered height | h13 (mm) | 40 | 40 | 40 | |||||||
| 4.7 | 站立高度 | stand height | h7 (mm) | 145 | 145 | 145 | |||||||
| 4.8 | 操作位置手柄桿最小/最大高度 | Height of tiller in drive position min./max. | h14 (mm) | 1075/1502 | 1075/1502 | 1075/1502 | |||||||
| 4.9 | 整車長度 | Overall length | l1 (mm) | 3130 | 3130 | 3130 | |||||||
| 4.10 | 到貨叉垂直面的長度 | Length to face of forks | l2 (mm) | 2060 | 2060 | 2060 | |||||||
| 4.11 | 整車寬度 | Overall width | b1/ b2 (mm) | 940/1106 | 940/1106 | 940/1106 | |||||||
| 4.12 | 貨叉尺寸 | Fork dimensions | s/e/l (mm) | 40/120/1070 | 40/120/1070 | 40/120/1070 | |||||||
| 4.13 | 貨叉外寬 | Distance between fork-arms | b5 (mm) | 240-700 | 240-700 | 240-700 | |||||||
| 4.14 | 軸距中心處離地間隙 | Ground clearance, center of wheelbase | m2 (mm) | 48 | 48 | 48 | |||||||
| 4.15 | 通道寬度：1000x1200托盤（1200跨貨叉放置） | Aisle width for pallets 1000 × 1200 crossways | Ast (mm) | 3420 | 3420 | 3420 | |||||||
| 4.16 | 通道寬度：800x1200托盤（1200沿貨叉放置） | Aisle width for pallets 800 × 1200 lengthways | Ast (mm) | 3530 | 3530 | 3530 | |||||||
| 4.17 | 轉彎半徑 | Turning radius | Wa (mm) | 1900 | 1900 | 1900 | |||||||
| 性能參數 Performance data | |||||||||||||
| 5.1 | 行走速度，滿載/空載 | Travel speed, laden/ unladen | (km/h) | 5.2/5.5 | 5.2/5.5 | 5.2/5.5 | |||||||
| 5.2 | 提升速度 滿載/空載 | Lifting speed, laden/ unladen | (mm/s) | 90/120 | 90/120 | 90/120 | |||||||
| 5.3 | 下降速度 滿載/空載 | Lowering speed, laden/ unladen | (mm/s) | 120/130 | 120/130 | 120/130 | |||||||
| 5.4 | 最大爬坡度 滿載/空載 | Max. gradeability, laden/unladen | (%) | 6/8 | 6/8 | 6/8 | |||||||
| 5.5 | 制動類型 | Service brake type | 電磁制動(electromagnetic) | 電磁制動(electromagnetic) | 電磁制動(electromagnetic) | ||||||||
| 電機，動力源 Electric-engine | |||||||||||||
| 6.1 | 驅動電機額定功率 S2 60分鐘 | Drive motor rating S2 60 min | (kW) | 3.0 | 3.0 | 3.0 | |||||||
| 6.2 | 起升電機額定功率 S3 15% | Lift motor rating at S3 15% | (kW) | 4.5 | 4.5 | 4.5 | |||||||
| 6.3 | 蓄電池，根據DIN 43531/35/36 A,B,C,no | Battery acc. To DIN 43531/35/36 A.B.C,no | no | no | no | ||||||||
| 6.4 | 電瓶電壓/標稱容量 K5 | Battery voltage/nominal capacity K5 | (V/Ah) | 24/280 | 24/280 | 24/280 | |||||||
| 6.5 | 電瓶重量 | Battery weight | (kg) | 275 | 275 | 275 | |||||||
| 其他數據 Addition data | |||||||||||||
| 8.1 | 驅動控制類型 | Type of drive control | 交流速度控制 | 交流速度控制 | 交流速度控制 | ||||||||
| 8.2 | 噪音水平 | Sound pressure level at the driver’s ear | (dB(A)) | ≤75 | ≤75 | ≤75 | |||||||
